Building Products Laminated EPS Insulation

Poly Shield® XR

Poly Shield® XR offers a tough, puncture resistant, option for the interior of warehouses and agricultural buildings. The white woven polypropylene membrane is laminated on one side of the EPS core and a reflective metalized facer on the other. Poly Shield® XR increases R-values compared to other popular options. The clean, washable and durable bright white finish can be left as is or can be painted or stucco finished. The white woven hybrid mesh design provides a high tensile strength which holds up to pressure washing and assuring you a lifetime of use. Renovators recognize its advantages and many architects are specifying Poly Shield® XR in their designs, particularly for pole barns or other buildings using post-frame construction.

application of Poly Shield XR insulation
application of Poly Shield XR insulation
application of Poly Shield XR insulation

Applications

Superior R-Value, strength, & brightness in a washable interior insulated sheathing for Warehouses & Agricultural Buildings. Please consult local building codes for system requirements. We recommend regular Poly Shield® instead of Poly Shield® XR for residential or inhabited commercial buildings.

Advantages

Cost Savings

EPS reduces energy costs and offers the highest R-value per dollar of any foam insulation board. Poly Shield® XR is lightweight and easy to install.

High, Stable R-value

The R-value of EPS is permanent because the only gas in EPS is air. Unlike Polyiso or XPS whose blowing agents outgas and therefore lose R-value, EPS R-values do not degrade over decades of use. When combined in a wall design facing dead air space, our reflective metalized facer increases R-value significantly.

Moisture Resistant

Cellofoam EPS is quick drying and does not readily absorb moisture from the air. Its closed-cell structure reduces the absorption and migration of moisture, and the facers surfaces are nearly impervious to moisture. When properly installed it does not deteriorate with age, and is resistant to mildew, rot, fungus, and bacteria. Not a vapor barrier.

Premium Quality

The EPS core of Poly Shield® XR meets or exceeds ASTM C578 specs, with excellent dimensional stability & compressive strength. Our white woven polymeric facer is our highest quality and most durable facer.

Environmentally Friendly

Cellofoam EPS contains no formaldehyde or ozone-depleting CFCs or HCFCs. Poly Shield's EPS core is 100% recyclable and may contain recycled material.

Manufactured to your Needs

Poly Shield® XR sheathing is available in 4 ft wide boards in lengths from 8 to 20 ft, in thicknesses from 1/2 to 6 inches, and in ASTM C578 nominal densities of 1.0, 1.25, 1.5, and 2.0 lb/ft3.

Downloads

Protect what matters most

We’re dedicated to manufacturing products that meet the highest standards of quality and performance. Need to know if Cellofoam’s products are right for your next project? Reach out to our team.
